管道 尺寸 |
od 在 英寸 |
作为一个。管道时间表 |
|||||||||||||||
|
5s. |
5. |
10s. |
10. |
20. |
30. |
40年代 ＆std。 |
40 |
60. |
80年代 ＆E.H. |
80 |
100. |
120. |
140. |
160. |
DBL. E.H. |
||
|
1/8 |
.405 |
.035 .1383 |
.049 .1863 |
.049 .1863 |
.068 .2447 |
068 .2447 |
0.95 .3145 |
0.95 .3145 |
|||||||||
|
1/4 |
.540 |
.049 .2570 |
.065 .3297 |
.065 .3297 |
.088 .4248 |
088 .4248 |
.119 .5351 |
.119 .5351 |
|||||||||
|
3/8 |
.675 |
.049 .3276 |
.065 .4235 |
.065 .4235 |
.091 .5676 |
.091 .5676 |
.126 .7338 |
.126 .7338 |
|||||||||
|
1/2 |
.840 |
.065 .5383 |
.065 .5383 |
.083 .6710 |
.083 .6710 |
.109 .8510 |
.109 .8510 |
.147 1.088 |
.147 1.088 |
.187 1.304. |
.294 1.714 |
||||||
|
3/4 |
1.050 |
.065 .6838 |
.065 .6838 |
.083 .8572 |
.083 .8572 |
.113 1.131 |
.113 1.131 |
.154 1.474 |
.154 1.474 |
.218 1.937 |
.308 2.441 |
||||||
|
1 |
1.315 |
.065 .8678 |
.065 .8678 |
.109 1.404. |
.109 1.404. |
.133 1.679. |
.133 1.679. |
.179 2.172 |
.179 2.172 |
.250 2.844 |
.358 3.659. |
||||||
|
1-1 / 4. |
1.660 |
.065 1.107 |
.065 1.107 |
.109 1.806 |
.109 1.806 |
.140 2.273 |
.140 2.273 |
.191 2.997 |
.191 2.997 |
.250 3.765 |
.382 5.214 |
||||||
|
1-1 / 2 |
1.900. |
.065 1.274 |
.065 1.274 |
.109 2.085 |
.109 2.085 |
.145 2.718 |
.145 2.718 |
.200 3.631 |
.200 3.631 |
.281 4.859 |
.400 6.408. |
||||||
|
2 |
2.375 |
.065 1.604 |
.065 1.604 |
.109 2.638 |
.109 2.638 |
.154 3.653 |
.154 3.653 |
.218 5.022 |
.218 5.022 |
.343 7.444 |
.436 9.029. |
||||||
|
2-1 / 2 |
2.875 |
.083 2.475 |
.083 2.475 |
.120 3.531 |
.120 3.531 |
.203 5.793 |
.203 5.793 |
.276 7.661 |
.276 7.661 |
.375 10.01 |
.552 13.70 |
||||||
|
3. |
3.500. |
.083 3.029. |
.083 3.029. |
.120 4.332 |
.120 4.332 |
.216 7.576 |
.216 7.576 |
.300 10.25 |
.300 10.25 |
.437 14.32 |
.600 18.58 |
||||||
|
3-1 / 2 |
4.000 |
.083 3.472 |
.083 3.472 |
.120 4.973 |
.120 4.973 |
.226 9.109 |
.226 9.109 |
.318 12.51 |
.318 12.51 |
.636 22.85 |
|||||||
|
4. |
4.500 |
.083 3.915 |
.083 3.915 |
.120 5.613 |
.120 5.613 |
.237 10.79 |
.237 10.79 |
.281 12.66 |
.337 14.98 |
.337 14.98 |
.437 19.01 |
.531 22.51 |
.674 27.54 |
||||
|
4-1 / 2 |
5.000 |
.247 12.53 |
.355 17.61 |
.710 32.53 |
|||||||||||||
|
5. |
5.563 |
.109 6.349 |
.109 6.349 |
.134 7.770. |
.134 7.770. |
.258 14.62 |
.258 14.62 |
.375 20.78 |
.375 20.78 |
.500 27.04 |
.625 32.96 |
.750 38.55 |
|||||
|
6. |
6.625 |
.109 7.585 |
.109 7.585 |
.134 9.290 |
.134 9.290 |
.280 18.97 |
.280 18.97 |
.432 28.57 |
.432 28.57 |
.562 36.39 |
.718 45.30. |
.864 53.16 |
|||||
|
7. |
7.625 |
.301 23.57 |
.500 38.05 |
.875 63.08 |
|||||||||||||
| 中等类型=英寸壁厚 大胆类型=磅的钢重量 |
|||||||||||||||||
|
管道 尺寸 |
od 在 英寸 |
作为一个。管道时间表 |
|||||||||||||||
|
5s. |
5. |
10s. |
10. |
20. |
30. |
40年代＆ STD。 |
40 |
60. |
80年代＆ E.H. |
80 |
100. |
120. |
140. |
160. |
DBL. E.H. |
||
|
8. |
8.625 |
.109 9.914 |
.109 9.914 |
.148 13.40. |
.148 13.40. |
.250 22.36 |
.277 24.70. |
.322 28.55 |
.322 28.55 |
.406 35.64 |
.500 43.39 |
.500 43.39 |
.593 50.87 |
.718 60.93 |
.812 67.76 |
.906 74.69 |
.885 72.42 |
|
9. |
9.625. |
.342 33.90 |
.500 48.72 |
||||||||||||||
|
10. |
10.750. |
.134 15.19 |
.134 15.19 |
.165 18.65 |
.165 18.70 |
.250 28.04 |
.307 34.24 |
.365 40.48 |
.365 40.48 |
.500 54.74 |
.500 54.74 |
.593 64.33 |
.718 76.93 |
.843 89.20 |
1.000 104.10 |
1.125 115.70. |
|
|
11. |
11.750. |
.375 45.55 |
.500 60.07 |
||||||||||||||
|
12. |
12.750. |
.156 21.07 |
.165 22.18 |
.180 24.16 |
.180 24.20. |
.250 33.38 |
.330 43.77 |
.375 49.56 |
.406 53.53 |
.562 73.16 |
.500 65.42 |
.687 88.51 |
.843 107.20 |
1.000 125.50 |
1.125 139.70 |
1.312 160.3 |
|
|
14. |
14.000 |
.156 23.07 |
.188 27.73 |
.250 36.71 |
.312 45.38 |
.375 54.57 |
.375 54.57 |
.437 63.37 |
.593 84.91 |
.500 72.09 |
.750 106.10 |
.937 130.70 |
1.093 150.70 |
1.250 170.20 |
1.406. 189.10 |
||
|
16. |
16.000 |
.165 27.90 |
.188 31.75. |
.250 42.05 |
.312 52.36 |
.375 62.58 |
.375 62.58 |
.500 82.77 |
.656 107.50 |
.500 82.77 |
.843 136.50 |
1.031. 164.80 |
1.218 192.30 |
1.427 223.50 |
1.593 245.10 |
||
|
18. |
18.000 |
.165 31.43 |
.188 35.76 |
.250 47.39 |
.312 59.03 |
.437 82.06 |
.375 70.59 |
.562 104.20 |
.750 138.20. |
.500 93.45. |
.937 170.80 |
1.156 208.00 |
1.375 244.10 |
1.562 274.20 |
1.781 308.50 |
||
|
20. |
20.000 |
.188 39.78 |
.218 46.05 |
.250 52.73 |
.375 78.60 |
.500 104.10 |
.375 78.60 |
.593 122.90 |
.812 166.40 |
.500 104.10 |
1.031. 208.90 |
1.280 256.10 |
1.500 296.40 |
1.750. 341.10 |
1.968 379.00 |
||
|
22. |
22.000 |
.188 43.80. |
.218 50.71 |
.250 58.07 |
.375 86.61 |
.500 114.81 |
.375 86.61 |
.875 197.41 |
.500 114.81 |
1.125 250.81 |
1.375 302.88 |
1.625 353.61 |
1.875 403.00 |
2.125 451.06 |
|||
|
24. |
24.000. |
.218 55.37 |
.250 63.41 |
.250 63.41 |
.375 94.62 |
.562 140.80 |
.375 94.62 |
.687 171.20 |
.968 238.10 |
.500 125.50 |
1.218 296.40 |
1.531 367.40. |
1.812 429.40 |
2.062 483.10 |
2.344 542.13 |
||
|
26. |
26.000 |
.312 85.60 |
.500 136.17 |
.375 102.63 |
.500 136.17 |
||||||||||||
|
28. |
28.000 |
.312 92.26 |
.500 146.85 |
.625 182.73 |
.375 110.64 |
||||||||||||
|
30. |
30.000 |
.250 79.43 |
.312 98.93 |
.312 98.93 |
.500 157.53 |
.625 196.08 |
.375 118.65 |
.500 157.53 |
|||||||||
|
32. |
32.000 |
.312 105.59 |
.500 168.21 |
.625 209.43 |
.375 126.66. |
.688 230.08 |
.500 168.21 |
||||||||||
|
34. |
34.000. |
.312 112.25 |
.500 178.89 |
.625 222.78 |
.375 134.67 |
.688 244.77 |
|||||||||||
|
36. |
36.000 |
.312 118.92 |
.625 236.13 |
.375 142.68 |
.750 282.35 |
.500 189.57 |
|||||||||||
| 中等类型=英寸壁厚 大胆类型=磅的钢重量 |
|||||||||||||||||
